Product Details:
|
| Number Of Row: | NU2217 EM | Type: | Cylindrical Roller Bearing |
|---|---|---|---|
| Innerring: | 85x150x36 Mm | Weight: | 3.61 Kg |
| Stock: | 5000pcs | Brand: | Neutral Packing/OEM |
| Application: | Combustion Turbines | ||
| Highlight: | NU2217 Cylindrical Roller Bearing,85x150x36 mm Cylindrical Roller Bearing,EM Cylindrical Roller Bearing |
||
| Inside Ø (mm): | 85 |
| Outside Ø (mm): | 150 |
| Width (mm): | 36 |
| max. Operating Temperature: | +120°C |
| min. Operating Temperature: | -40°C |
| Tolerance for inside Ø (mm): | 0/-0,02 |
| Tolerance for outside Ø (mm): | 0/-0,018 |
| Tolerance for width (mm): | 0/-0,2 |
| Version: | NU |
| Bore: | cylindrical |
Cylindrical Roller Bearing Description
Cylindrical roller bearings (CRBs) have a simple structure of cylindrical rollers in linear contact with the raceways. They offer high load capacity under primarily radial loads. Low friction between the rollers and ring ribs makes these bearings suited for high speed rotation.
Cylindrical Roller Bearing Product number
| Bearing Number | principal dimensions(mm) | Weight (Kg) | ||||
| d | D | B | r1min | rsmin | ||
| NU2210 | 50 | 90 | 23 | 1.1 | 1.1 | 0.580 |
| NU2211 | 55 | 100 | 25 | 1.5 | 1.1 | 0.787 |
| NU2212 | 60 | 110 | 28 | 1.5 | 1.5 | 1.900 |
| NU2213 | 65 | 120 | 31 | 1.5 | 1.5 | 1.47 |
| NU2213 | 65 | 140 | 48 | 2.1 | 2.1 | 3.25 |
| NU2214 | 70 | 125 | 31 | 1.5 | 1.5 | 1.53 |
| NU2215 | 75 | 130 | 31 | 1.5 | 1.5 | 1.58 |
| NU2216 | 80 | 140 | 33 | 2.0 | 2.0 | 1.95 |
| NU2217 | 85 | 150 | 36 | 2.0 | 2.0 | 2.58 |
| NU2218 | 90 | 160 | 40 | 2.0 | 2.0 | 3.18 |
| NU2219 | 95 | 170 | 43 | 2.1 | 2.1 | 3.89 |
| NU2220 | 100 | 180 | 46 | 2.1 | 2.1 | 4.68 |
| NU2220 | 110 | 200 | 38 | 2.1 | 2.1 | 4.80 |
| NU2224 | 120 | 215 | 58 | 2.1 | 2.1 | 8.38 |
| NU2226 | 130 | 230 | 64 | 3.0 | 3.0 | 10.50 |
| NU224 | 120 | 215 | 40 | 2.1 | 2.1 | 5.75 |
| NU226 | 130 | 230 | 40 | 3.0 | 3.0 | 6.45 |
Cylindrical Roller Bearing Applications
1. Material handling machinery:mining machinery, textile machinery, lifting equipment, Agricultural machinery: tractors, harvesting machinery, etc.
2. Heavy-duty mining machinery: metallurgical machinery, mining machinery, lifting machinery, loading and unloading machinery, industrial vehicles, cement equipment, etc.
3. Construction Machinery: forklifts, earth moving machinery, compaction machinery, concrete machinery, etc.
4. The general petrochemical machinery: oil drilling machinery, oil refining machinery, chemical machinery, gas compressors, paper machinery, printing machinery, etc.
5. Machine tools: forging machinery, foundry machinery, woodworking machinery, etc.
6. Car: truck, road, bus, car, modified car, motorcycle ,etc.
